Oberton 8NB201 8 Ohm
| Anzahl | Stückpreis |
|---|---|
| Bis 2 |
196,00 €*
|
| Bis 4 |
194,00 €*
|
| Bis 6 |
192,00 €*
|
| Ab 7 |
191,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW11476
Produktinformationen "Oberton 8NB201 8 Ohm"
- Oberton 8NB201
- 95 db 1W / 1m average sensitivity
- 51 mm high temperature voice coil
- 400 W AES program power
- Water protected cone (front)
- Epoxy anti-corrosion coating of top and back plates of magnet structure
Oberton 8NB201 8 Ohm SPECIFICATIONS
|
Nominal Diameter Impedance Minimum Impedance Power Capacity AES ¹ Program Power ² Sensitivity Frequency Range Voice Coil Diameter Voice Coil Material Voice Coil Former V. C. Winding Depth Magnet Gap Depth Cone Material Basket Magnet Flux Density |
8"/210 inch/mm 8 Ohm 6.40 Ohm 200 W 400 W (200-2000 Hz) 95 dB/W/m 65 – 3000 Hz 51 mm Cooper Kapton™ 14 mm 7 mm Paper with glassfiber Die cast aluminium Neodymium 1.25 T |
THIELE-SMALL PARAMETERS 8NB201
|
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
|
70.56 Hz 5.97 0.255 0.245 12.54 Litres 22.67 grams 5.27 Ohms 202 cm2 ±5.25 mm 0.224 mm/N 14.41 T.m 0.96 mH |
MOUNTING INFORMATION
|
Overall Diameter Baffle Hole Diameter Mounting Holes Bolt Circle Diameter Overall Depth Net Weight |
225 mm 187 mm 8 with dia. 6.5 mm 210 mm 89 mm 2.38 kg |
| Coaxial: | NEIN |
|---|---|
| Größe: | 8" |
| Impedanz: | 8 Ohm |
| Magnet: | Neodym |
| Qts: | 0,21 - 0,25 |
| Sperrgut: | NEIN |
| X-MAX: | 5,1 - 10,0 mm |
