Eighteensound ND3BE 8 Ohm

Produktinformationen "Eighteensound ND3BE 8 Ohm"
The ND3BE 1.4 inch exit Natural Sound neodymium high frequency compression driver has been designed for high level sound systems application. The unit has been designed to fulfill tight geometrical requirements, thanks to its ultra compact 109mm overall diameter.

In addition to the next-gen titanium diaphragm of the standard ND3T version, pure Beryllium has been used for this benchmark component, avoiding spurious resonances at very high frequencies, assuring the lowest possible harmonic distortion over the whole working range.

A proprietary treated Nomex former is used as Nomex shows a 30% higher value of tensile elongation at a working operative temperature (200°C) when compared to Kapton. Moreover, this proprietary former material is also suitable for use in higher moisture content environments.

Despite of its compact size, the ND3BE neodymium magnet assembly has been designed to obtain 20KGauss in the gap for major benefits in transient response. The motor structure, throughout the precisely coherent metal alloy phase plug with 4 circumferential slots and copper ring on the pole piece, reduces inductance effect and distortion.

The diaphragm kit self centering design allows high precision mounting and at the same time makes very easy the servicing procedure.

The ability to perform properly under inclement weather conditions is a key point of the Eighteen Sound philosophy. Hence, a special treatment is applied to the magnet and the top and back plates of the magnetic structure in order to make the driver more resistant to the corrosive effects of salts and oxidization. This treatment is more effective than any other coating commonly used.


DATENBLATT

Coaxial: NEIN
Diaphragma / Dome: Beryllium / Nitride coated / Carbon
Größe: 1,4"
Hochtöner Bauform: Kompressionstreiber
Impedanz: 8 Ohm
Magnet: Neodym
Sperrgut: NEIN
