Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW10232
Produktinformationen "Eighteensound HD2080T 8 Ohm"
The HD2080T 2-inch exit high frequency compression driver has been
designed for use in high quality installed audio systems, where weight
is not the key issue. The motor structure, throughout the precisely
coherent phase plug with 3 circumferential slots and copper ring on the
pole piece, reduces inductance effects and distortion. Four top plate
air ducts have been designed to act as a loading chamber for the
diaphragm, implementing mid band distortion and response figures. The
HD2080T diaphragm assembly is composed of a titanium dome sandwiched to a
proprietary treated polyester suspension unit. It has been designed to
maintain low resonance, lowering the minimum crossover point value at
1,2kHz. Thanks to its physical properties, the proprietary treated
Nomex former has a 30% higher value of tensile elongation at a working
operative temperature (200°C) when compared to Kapton. This feature
enables proper energy transfer control from the voice coil to the dome
in real working conditions. Moreover, this proprietary former material
is also suitable to for use in higher moisture content environments. The
HD2080T powerful ceramic magnet assembly has been designed to obtain
16KGauss in the gap. Excellent heat dissipation and thermal exchange are
guaranteed by the direct contact between the magnetic structure and the
aluminum cover which leads to a lower power compression value.
Coaxial: | NEIN |
---|---|
Diaphragma / Dome: | Titanium |
Größe: | 2" |
Hochtöner Bauform: | Kompressionstreiber |
Impedanz: | 8 Ohm |
Magnet: | Ferrit |
Sperrgut: | NEIN |
