Anzahl | Stückpreis |
---|---|
Bis 2 |
670,00 €*
|
Bis 4 |
664,00 €*
|
Bis 6 |
658,00 €*
|
Ab 7 |
652,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW10037
Produktinformationen "Eighteensound 18NLW9000 8 Ohm"
The 18NLW9000 is a low frequency 18 inch neodymium high performance
transducer and has been optimized for direct radiation and bandpass
subwoofer cabinet designs. For optimum results recommended amplifier
should be able to deliver 3600 Watt program power without clipping. At
the heart of the updated design stays the improved double silicon spider
based on DSS technology, letting the 18NLW9000 being able to control
the moving mass with high linearity, showing an exceptional stability of
mechanical parameter values in the long term. The transducer design
features include a high performance large displacement suspension system
for improved cone control at very high level of SPL matching. Eighteen
Sound engineers have obtained the best possible results with today's
available materials in terms of clean and undistorted LF reproduction at
a ultra high SPL, with the lowest possible power compression figure.
The state-of-the-art 5,3" diameter ISV copper voice coil enables the
18NLW9000 to handle up to 3600W program power. Bl force factor, as well
as all other electro-dynamic parameters, are linear within the working
range allowing 60mm of excursion before damage.
The 18NLW9000 has
been developed after intense FEA and fluidodynamics simulation and
testing, focusing on dissipating the heat generated by the powerful 5.3"
coil. Special attention was given to the optimization of air flow into
the gap without introducing audible noise. A special low density
material air diffractor placed into the backplate acts as a cooling
system, increasing the power handling capability and lowering the power
compression figure. The low distortion and sound quality are further
improved by an aluminum demodulating ring (SDR technology) that flatten
impedance and phase with a constant power transfer. The carbon fiber
reinforced, straight ribbed cone shows a proprietary resin treatment for
extra pulp strength and water repellent properties. A special coating
applied to both the top and back plates makes the transducer far more
resistant to the corrosive effects of salts and oxidization.
Coaxial: | NEIN |
---|---|
Größe: | 18" |
Impedanz: | 8 Ohm |
Magnet: | Neodym |
Qts: | 0,31 - 0,35 |
Sperrgut: | NEIN |
X-MAX: | 10,1 - 15,0 mm |
