Produktnummer:
SW10148
Produktinformationen "Eighteensound 18LW2400 8 Ohm"
The 18LW2400 is an 18 inch extended low frequency loudspeaker designed
for high SPL subwoofer applications in either a reflex, bandpass or horn
loaded configuration. Compared to our industry standard 18LW1400, the
18LW2400 provides higher maximum SPL, increased program power handling
and lower power compression. For optimum results we recommend
amplifiers able to deliver 2400 Watt program power without clipping.
Transducer design features include a large displacement suspension
system which, in conjunction with a fiberglass reinforced, straight
ribbed cone and the Eighteen Sound proprietary Double Silicon Spider
(DSS) technology, allows an ultra-linear piston action and provides full
mechanical control across the entire working range. The 100 mm (4 in)
inside-outside copper voice coil based on Interleaved Sandwich Voice
coil (ISV) technology provides high levels of thermal stability and
durability. In order to furtherly increase power handling and reduce
power compression figure, 18LW2400 uses the same voice coil ventilation
technology developed for our flagship 9000 neodymium transducer series. A
special low density material air diffractor has been placed into the
backplate acting as a cooling system, increasing power handling
capability and lowering the power compression figure. As a final result
Eighteen Sound engineers obtained almost 1 dB reduction in full power
power compression value if compared to 18LW1400, and an increased
program power handling value of 2400 Watt. The low distortion and
unmatched sound quality of the 18LW2400 has been significantly improved
by Double Demodulating Rings (DDR) embedded in the pole piece of the
magnetic structure. These have been designed to reduce the
intermodulation and harmonic distortion while improving the transient
response. 10% reduction in weight have been obtained optimizing the
magnetic structure through advanced FEA CAD simulation tools. 18LW2400
is able to perform properly under inclement weather conditions: the
exclusive cone treatment improves pulp strength and gives water
repellent properties to both sides of the cone. In addition, the special
treatment applied to top and back plates of the magnetic structure is
far more resistant to the corrosive effects of salts and oxidization.
Coaxial: | NEIN |
---|---|
Größe: | 18" |
Impedanz: | 8 Ohm |
Magnet: | Ferrit |
Qts: | 0,31 - 0,35 |
Sperrgut: | NEIN |
X-MAX: | 5,1 - 10,0 mm |
