Produktinformationen "Eighteensound 15LW2400 4 Ohm"
The 15LW2400 has been developed as an evolution of the 15LW1401 low
frequency transducer, setting a new industry standard in 15" (380 mm)
ferrite high performance transducers. The speaker has been designed for
use as a low bass or sub-woofer component in a compact cabinet (60 -
130 lt) reflex configuration, providing clean, linear, undistorted low
frequency reproduction at very high power levels. The high excursion
capabilities of the Double Silicon Spider (DSS) enable the 15LW2400 to
achieve high levels of linear travel and maintain full control of the
moving mass. The fiberglass fiber reinforced, straight-sided ribbed cone
assures smooth response with high internal damping. The 100 mm Ø
copper voice coil employs the Interleaved Sandwich Voice coil (ISV)
technology, in which a high strength fiberglas former carries windings
on both the outer and inner surfaces to achieve a mass balanced coil.
The weight of the windings are evenly distributed, providing a uniform
motive drive. The already low distortion and sound quality of 15LW2400
has been further improved by the Double Demodulation Rings (DDR)
designed to dramatically reduce the intermodulation and harmonic
distortion whilst improving the transient response. Excellent heat
dissipation has been achieved by incorporating air channels between the
basket and the top plate of the magnet. Further ventilation is provided
using air vents in the back plate that direct air into the lower part of
the voice coil gap. In order to furtherly increase power handling and
reduce power compression figure, 15LW2400 uses the same voice coil
ventilation technology developed for our flagship 9000 neodymium
transducer series. A low density material air diffractor is placed into
the backplate acting as a cooling system, increasing power handling
capability and lowering the power compression figure. As a final result
the transducer shows 1 dB reduction in full power power compression
value if compared to 15LW1401, and a program power handling value of
2400 Watt. 10% reduction in weight have been obtained optimizing the
magnetic structure through advanced FEA CAD simulation tools. The
15LW2400 ability to perform properly under inclement weather conditions
has been achieved using an exclusive cellulose treatment which gives
water repellent properties to both sides of the cone. In addition, an
epoxy coating is applied to metal plates in order to resist against the
corrosive effects of salts and oxidization.
Coaxial: | NEIN |
---|---|
Größe: | 15" |
Impedanz: | 4 Ohm |
Magnet: | Ferrit |
Qts: | 0,21 - 0,25 |
Sperrgut: | NEIN |
X-MAX: | 5,1 - 10,0 mm |
