Anzahl | Stückpreis |
---|---|
Bis 2 |
311,00 €*
|
Bis 4 |
308,00 €*
|
Bis 6 |
306,00 €*
|
Ab 7 |
303,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW10158
Produktinformationen "Eighteensound 15LW1401 4 Ohm"
The 15LW1401 is a low frequency loudspeaker which sets a industry
standard in 15" (380 mm) high performance transducers. The transducer
has been designed for use as a low bass or sub-woofer component in
either a more compact reflex, bandpass or horn loaded configuration. It
provides clean, linear, undistorted low frequency reproduction at very
high power levels, as part of a high power fullrange system. In its
reflex configuration, it can be used in extremely compact enclosures,
(65 - 130 lt) which is ideal for touring applications, including indoor
and outdoor concert reinforcement systems. The high excursion
capabilities of the surround and suspension system, in conjunction with
the Eighteen Sound Double Silicon Spider (DSS), enable the 15LW1401 to
achieve high levels of linear travel and maintain full control of the
moving mass. The carbon fiber reinforced, straight-sided ribbed cone
assures smooth response and exceptional strength, with maximum
reliability under high mechanical stress. The 100 mm Ø copper voice
coil employs the Interleaved Sandwich Voice coil (ISV) technology, in
which a high strength fiberglas former carries windings on both the
outer and inner surfaces to achieve a mass balanced coil. The weight of
the windings are evenly distributed, providing a uniform motive drive.
This, in conjunction with the use of state-of-the-art high temperature
resin adhesives, results in an extremely linear motor assembly. The
already low distortion and sound quality of this loudspeaker has been
further improved by the Double Demodulation Rings (DDR) designed to
dramatically reduce the intermodulation and harmonic distortion whilst
improving the transient response. Excellent heat dissipation has been
achieved by incorporating air channels between the basket and the top
plate of the magnet. Further ventilation is provided using air vents in
the back plate that direct air into the lower part of the voice coil
gap. Maximum flux concentration and force factor is assured by the
unique shape and design of the top and back plates, researched and
designed using Magnetic Flux FEA CAD resource. The 15LW1401's ability
to perform properly under inclement weather conditions has been achieved
using an exclusive cone treatment improving pulp strength, which gives
water repellent properties to both sides of the cone. In addition, a
special treatment has been applied to both the top and back plates that
is far more resistant to the corrosive effects of salts and oxidization
than any other in use today.
Coaxial: | NEIN |
---|---|
Größe: | 15" |
Impedanz: | 4 Ohm |
Magnet: | Ferrit |
Qts: | 0,26 - 0,30 |
Sperrgut: | NEIN |
X-MAX: | 5,1 - 10,0 mm |
