Anzahl | Stückpreis |
---|---|
Bis 2 |
304,00 €*
|
Bis 4 |
302,00 €*
|
Bis 6 |
299,00 €*
|
Ab 7 |
296,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
The neodymium magnet assembly assures high flux concentration, low power compression and excellent heat exchange because the external magnet configuration is considerably more efficient than traditional under-pole magnet topology.
Consequently, high levels of force factor and power handling with an optimum power to weight ratio have been achieved.
Direct coupling of the special design basket and magnetic assembly with the large heat sink facilitates thermal flux through the ambient air, increasing the power handling capabilities and lowering the power compression.
The curvilinear paper cone has been created with a special high strength wood pulp designed to achieve the best possible linearity within its intended frequency range and to control bell-mode resonances around the cone circumference. The cone is carried by a multiroll suspension formed from a linen-like material which is more resistant to aging and fatigue than traditional materials.
The already low distortion and sound quality are further improved by the use of Double Demodulating Rings technology (DDR) designed to dramatically reduce the intermodulation and harmonic distortion and improve the transient response.
The 12ND710 implements Interleaved Sandwich Voice coil technology (ISV), in which an aluminum coil is wound inside and outside a high strength fiberglas former, providing a better thermal and mechanical performance than conventional coils.
Coaxial: | NEIN |
---|---|
Größe: | 12" |
Impedanz: | 16 Ohm |
Magnet: | Neodym |
Qts: | 0,26 - 0,30 |
Sperrgut: | NEIN |
X-MAX: | 0,1 - 5,0 mm |
