Eighteensound 10NW650 16 Ohm
| Anzahl | Stückpreis |
|---|---|
| Bis 2 |
213,00 €*
|
| Bis 4 |
211,00 €*
|
| Bis 6 |
209,00 €*
|
| Ab 7 |
207,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW10085
Produktinformationen "Eighteensound 10NW650 16 Ohm"
The 10NW650 is a neodymium 10 inch size woofer. The transducer has been
developed in response to a specific market requirement for a light
weight design that combines excellent linearity with high power handling
capabilities. The 10NW650 is primarily intended for use as a low
frequency driver for line-arrays as well as high quality 2-way or
multiway reflex enclosures. The low pass filter might be positioned as
high as 2000Hz. The high grade neodymium magnet assembly assures high
flux concentration and low power compression. The levels of force factor
and power handling are, as a consequence, at the upper professional
level with best power to weight ratio. The 65mm Ø state-of-the-art,
edgewound aluminum wire voice coil is wound on a high strength fiberglas
former. The voice coil is cooled through airways placed between the
chassis back plate and the magnet faceplate and carefully designed
ventilation ducts made into the metal back plate. The curvilinear paper
cone is formed using a special high strength wood pulp, designed to
achieve the best possible rigidity and stiffness. Due to the increasing
use during outdoor audio events, the ability to perform in humid
environments is an extra key feature of the 10NW650. This is achieved
trough an exclusively developed cone treatment which renders the cone
humidity repellent while does not increasing the total moving speaker
mass. In addition, a special epoxy treatment is applied to the top and
back plates making the transducer far more resistant to the corrosive
effects of salts and oxidization.
| Coaxial: | NEIN |
|---|---|
| Größe: | 10" |
| Impedanz: | 16 Ohm |
| Magnet: | Neodym |
| Qts: | 0,26 - 0,30 |
| Sperrgut: | NEIN |
| X-MAX: | 5,1 - 10,0 mm |
