Anzahl | Stückpreis |
---|---|
Bis 2 |
241,00 €*
|
Bis 4 |
239,00 €*
|
Bis 6 |
237,00 €*
|
Ab 7 |
235,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW10087
Produktinformationen "Eighteensound 10NMB420 16 Ohm"
The 10NMB420 neodymium transducer has been developed in response to a
specific market requirement for a 10" midbass driver that combines
excellent linearity with good efficiency and high power handling
capabilities. The 10NMB420 is primarily intended for use as a midbass
driver in line-arrays as well as high quality 2-way or multiway reflex
enclosures. The low pass filter might be positioned as high as 2000Hz.
The extremely powerful external neodymium magnet assembly assures high
flux concentration, low power compression and excellent heat exchange.
The levels of force factor and power handling are, as a consequence, at
the upper professional level with best power to weight ratio. The 65mm Ø
state-of-the-art, aluminum wire voice coil employs Interleaved Sandwich
Voice coil (ISV) technology. It is composed by a high strength
fiberglas former used to carry windings on both the outer and inner
surfaces, in order to achieve a mass balanced coil. This results in an
extremely linear motor assembly which, in conjunction with the highly
advanced design of the magnetic structure, provides a high BL force
factor. The voice coil is cooled through airways placed between the
chassis back plate and the magnet faceplate. In this way heated air is
channeled away from the voice coil and the gap. Another technology
present into the 10NMB420 is the SDR (Single Demodulating Ring), used to
reproduce instantaneous peak on mid frequencies, reducing
intermodulation distortion. Thanks to the increasing use during outdoor
audio events, the ability to perform in humid environments is an extra
key feature of the 10NMB420. This is achieved trough an exclusively
developed cone treatment which renders the cone humidity repellent while
does not increasing the total moving speaker mass.
Coaxial: | NEIN |
---|---|
Größe: | 10" |
Impedanz: | 16 Ohm |
Magnet: | Neodym |
Qts: | 0,31 - 0,35 |
Sperrgut: | NEIN |
X-MAX: | 0,1 - 5,0 mm |
